Simcenter 3D Advanced Flow

Product Simulation and Analysis for Applications Involving Fluid Flow.

Category: Siemens Simcenter Course
Course Type: Scheduled
Duration: 2 Days
Location: Emixa Office, Client Site, Remote (Online)
User Level: Beginner to Intermediate

Who’s it for?

The Simcenter 3D Advanced Flow Analysis course introduces product simulation and analysis for applications involving fluid flow. It is intended for design engineers and analysts who want to learn how to analyse specific cases of fluid flow analysis models in Simcenter 3D. This course covers the complete analysis simulation process. It includes model preparation, meshing, applying boundary conditions, solving, and post-processing the results.

Course Agenda

From CFD introduction to high speed flows, after this 2 day course, you will learn the complete analysis simulation process.

• Fluid volume creation & meshing
• Non-Newtonian fluids
• Meshing and material properties
• Periodic flows
• (CFD) introduction
• High speed flows
• Flow initial and boundary
• Flow mapping
• Flow solution and parameters
• Particle tracking
• Moving frames of reference
• Mixtures and humidity

Pre-requisites

Simcenter 3D thermal course.
